COOLER MASTER MWE 550 V3 550W 80 Plus Bronze Non Modular ATX 3.1 Power Supply
Feature of COOLER MASTER MWE 550 V3 550W 80 Plus Bronze
MWE BRONZE 550 V3 230V POWER EVOLVER
ATX 3.1 support & 12V-2x6 connector High temperature resilience Quiet HDB fan 80 Plus Bronze certified efficiency Embossed cable 5-year warranty
POWER EVOLVED
Cooler Master Power Supply Bronze presents the MWE 550W Power Supply, the upgraded version of the MWE Bronze featuring AT 3.1 support, high temperature resilience, a smart DC-to-DC + LLC circuit design, a quiet HDB fan, 80 Plus Bronze efficiency, an embossed cable, and a5-year warranty.
ATX 3.1 SUPPORT
Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated
maximum wattage, this unit is ideal for use with the 40 series GPUs.
*All performance stats confirmed in 25°C ambient temperature testing.
EMBOSSED CABLE
An embossed cable texture provides a softer and overall improved grip with a pleasing aesthetic.
QUIET HOB FAN
A hydrodynamic bearing fan delivers long- lasting quiet and effective cooling.*All
performance stats confirmed in 25°C ambient temperature testing.
Get the best 80 Plus Bronze psu power supply price from us today!
Specifications of COOLER MASTER MWE 550 V3 550W 80 Plus Bronze
| Model Number | MPE-5501-ACABW-3BIN |
| ATX Version | ATX 12V Ver. 3.1 |
| PFC | Active PFC |
| Input Voltage | 200-240V |
| Input Current | 5A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch |
| Fan Size | 120mm |
| Fan Bearing | HDB |
| Efficiency | >88% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Bronze EU 230V |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-40°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | >16ms |
| MTBF | >100,000 Hours |
| Protections | UVP / OVP / OPP / OTP / SCP |
| Regulatory | TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.) |
| Series | MWE Bronze Series |
| Category | 500 to 750W |
| Modular | Non Modular |
| 80 Plus | Bronze |
| Form Factor | ATX |
| Watts | 550W |
| ATX 24 Pin Connectors | 1 |
| EPS 8 Pin / 4+4 Pin Connectors | 2 |
| SATA Connectors | 6 |
| Peripheral 4 Pin Connectors | 3 |
| PCI-e 6+2 Pin Connectors | 2 |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
