AOC 22P2T 22 Inch FHD 75Hz VA Panel 72% SRGB 4MS Business Monitor

Features of AOC 22P2T 22 Inch FHD 75Hz VA Panel 72% SRGB 4MS Business Monitor



• Windows certified 10-point projected capacitive touchscreen [*], with a vast library of Windows applications at your fingertips.
• VA wide-viewing-angle technology for clearer and sharper images, with a high static contrast ratio of 3000:1.
• Features DP, HDMI, and DVI interfaces, and includes two built-in 2W speakers for easy connection to entertainment devices and direct playback of high-definition content.
• The USB 3.2 Gen1 port delivers a fast data transfer experience, making it an ideal solution for connecting mobile devices. The yellow port also supports fast charging for USB devices.
• DCR (Dynamic Contrast Ratio) technology, with a dynamic contrast ratio of up to 50,000,000:1.
• DCB (Dynamic Color Boost) technology, with 5 color enhancement modes; Eco Mode, with 6 brightness scene modes.
• Low blue light setting: Easily switch to low blue light scene mode to reduce the impact of harmful blue light.
• Clear Vision feature makes low-resolution images and text clearer and sharper.
• HDR Mode setting optimizes and adjusts image color and contrast to simulate HDR effects.
• Supports I-Menu adjustment software, allowing for flexible parameter adjustment.
• Supports e-Saver management software, intelligent shutdown, and energy saving.
• Z-shaped folding bracket, flexible tilt and large angle adjustment, allowing for complete control.
• IP65 front waterproof and dustproof, protecting the product from daily water splashes and dust damage, extending its service life.
• Point distance: 0.24825(H)mm x 0.24825(V)mm
• Screen size: 476.64(H) x 268.11(V) mm
• Contrast ratio (typical/minimum): 3000:1/2000:1
• Dynamic contrast ratio (typical): 50000000:1
• Scan frequency: Horizontal: 30k - 85kHz / Vertical: 48 - 75Hz
• Maximum resolution: 1920x1080@60Hz (DVI) / 1920x1080@75Hz (D-SUB, HDMI, DisplayPort)
• Display color: 16.7M
• Color gamut (typical value): 72% NTSC color gamut area (based on CIE 1931)/ 87% NTSC color gamut area (based on CIE 1976)
• HDCP function: Have
• Plug and play: VESA DDC2B/CI
• Rated power supply: 20Vdc, 2.25A
• Power consumption: Normal operating power: 20W (typical value); Standby power: ≤0.5W
• Wall-mounted: VESA 100mm×100mm
• Inclination: -5° to 90°
• Vertical rotation: None
• Height adjustment: None
• Rotate left and right: None
• [*]: Brightness specifications are typical values from AOC labs. Measured with brightness/contrast at maximum under factory default settings. Values may vary slightly depending on the testing environment or individual product; please refer to the actual product.
• [*]: GtG response time is a typical value from AOC labs, measured with Overdrive set to "Strong". Values may vary slightly depending on the testing environment or individual product; please refer to the actual product.
• [*]: Color gamut specifications are typical values from AOC labs, measured with contrast at maximum under factory default settings. Values may vary slightly depending on the testing environment or individual product. Please refer to the actual product.
• [*]: 10-point touch supports operating systems Win11/Win10/Win8.1/Win8/Win7.
• [*]: According to VESA standards, different operating systems and graphics cards may have a certain error (+/-1Hz) when calculating refresh rate (field frequency). Please refer to the actual product for the specific refresh rate (field frequency).



Specifications of AOC 22P2T 22 Inch FHD 75Hz VA Panel 72% SRGB 4MS Business Monitor



Model	22P2T
Screen Size	22 Inch
Display	FHD
Panel Type	VA
Resolution	1920 x 1080
Response Time	4ms
Refresh Rate	75Hz
Aspect Ratio	16:9
Contrast Ratio	3000:1
Screen Surface	FLAT
Brightness	250 cd/m²
Viewing Angle	178°/178°
Color Gamut	72% NTSC
Usage	HOME,BUSINESS
Connectivity	D-SUB,DVI,HDMI,DISPLAY PORT,USB
Built - In Speaker	Yes
Warranty	3 Years
Note	Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only.
